ACR39T-A1 Carry-on USB Flash Drive Smart Card Reader

ACR39T-A1 Carry-on USB Flash Drive Smart Card Reader

Features:

• The ACR39T-A1 uses modern new technology in the smart card reader industry

• It is compact and powerful enough to meet the stringent requirements of a wide range of smart card applications

• The ACR39T-A1 supports ISO 7816-compliant smart cards, including a wide range of memory cards and microprocessor cards compliant with T=0 and T=1 protocols.

• It is fully compliant with PC/SC and CCID specifications and supports a wide range of operating systems including Windows®, Linux, and Mac OS®.

• The ACR39T-A1 can also be used on mobile devices running Android™ 3.1 and higher

• The ACR39T-A1 weighs about the same as a USB stick, making it a device that can be taken anywhere.

• Supports ISO 7816 Class A, Class B and Class C (5 V, 3 V, 1.8 V) cards, 1.6 V cards

• Support for microprocessor cards with T=0 or T=1 protocols

• Support for various memory cards, e.g. I2C bus protocol (blank memory cards) with 128 bytes per page

• Memory card with 1K bytes of EEPROM smart memory and write protection

• Memory cards with 256 bytes of EEPROM intelligent memory and write protection

• Protocol and parameter selection (PPS) support

• Short circuit protection

• Application programming interface: PC/SC support; CT-API support (via PC/SC upper layer package)

Specification:

• Dimensions: 49.5*21.5*9.0mm

• Weight: 8.5g

• USB interface protocol: USB CCID

• Connector type: Standard A type

• Power supply: USB port power extraction

• Speed: USB Full Speed (12Mbps)

• Number of card slots: 1 standard SM size card slot

• Standard: IS078161-3 part, Type A, Type B, and Type C (5V, 3V, 1.8V)

• Protocol: T=0; T=1; memory card support

• Supported operating systems: Windows; Linux; MAC OS; Solaris; Android

Package includes:

• 1 x Card Reader
