Aixun SP3005 30V / 5A Intelligent Interconnection 4-digit Display CNC Programmable DC Power Supply

Aixun SP3005 30V / 5A Intelligent Interconnection 4-digit Display CNC Programmable DC Power Supply

Function:

• Low noise ripple, efficient and stable, the noise ripple is ≤2mV rms / 3mA rms

• Over-voltage/current protection, constant voltage/current output

• Support Type-C 30W fast charging QC/PD protocols output

• 3.5-inch HD IPS screen, real-time clear display of parameters/modes

• Dual control through knob and buttons, precise adjustment

• USB communication and remote OTA upgrade, unlimited functions expansion

• Adjust the voltage/current to three decimal places and preset multiple sets of output voltage/current

Features:

• SP3005 CNC Programmable DC Power Supply, redefining precision power delivery

• Designed with ultra-low noise ripple (≤2mVrms/3mArms) and 30% lower efficiency loss, it ensures high stability and minimal interference for demanding applications

• Offers micro-level voltage/current adjustment down to three decimal places, supported by high precision 4-figure display

• Featuring dual control modes (knob + buttons), it provides intuitive and accurate operation

• Built-in CV/CC modes, OVP/OCP protection, and multi-group preset outputs meet diverse testing and development needs

• Stay future-ready with USB communication and OTA remote upgrade, allowing unlimited function expansion

• The Type-C 30W fast charging output supports QC/PD protocols

• A 3.5-inch HD IPS screen displays parameters and modes in real time for clear visibility

• Ideal for audio equipment development, maintenance and debugging, electronics lab experiments, and low-noise sensor power supply,SP3005 is the perfect choice for precision-focused professionals

Specification:

• Product Name: CNC Programmable DC Power Supply

• Brand: AiXun

• Model: SP3005

• Input voltage: 230V

• Communication: USB

• Display type: 3.5 inch IPS Screen

• Material: Sheet metal + plastic

• Rated power: 150W (150W square transformer)

• Voltage/current range: 0~30V/0~5A adjustable

• Load regulation: Voltage: ≤ 0.01%+2mV/Current: ≤0.1%+5mA

• Linear regulation: Voltage: ≤ 0.01%+3mV/ Current: ≤ 0.1%+3mA; Ripple (20hz-20M)

• Voltage: ≤ 2mV rms/ Current: ≤ 3mA rms (ripple 1MV)

• Working mode: CC/CV modes; OV/OC protection

• Net weight: 4.6kg

• Dimensions: 200*100*170mm

Package includes:

• 1 x Power Supply

• 1 x Power Cord

• 1 x Banana Plug Alligator Clip
