Atten ST-965 Intelligent Lead-Free Soldering Station for Mobile Phone Motherboard Repair

Atten ST-965 Intelligent Lead-Free Soldering Station for Mobile Phone Motherboard Repair

Features:

• For easy temperature setting, can quickly preset the temperature value; Long press the “1 or 2 or 3” button ( more than 3 seconds ) to store the temperature value

• Temperature lock function, under the Loc menu, press “▲” and “▼” buttons to turn on/off. [1] [3] button to switch menus up and down, [2] button to exit and save settings

• ℃/℉ is available and exchangeable

• Temperature calibration, when the real temperature is lower than the display temperature, the compensation takes a negative temperature value. When the real temperature is higher than the display temperature, take a positive temperature value.

• Auto-sleep function, sleep time: 10~60 minutes (default 10). The heating element temperature is 200 °C under sleep status. In sleep mode, pick up the soldering tool or press any key to automatically resume normal operation

• Under the H-L menu, press the “▲” and “▼” buttons to set the upper /lower temperature values and OFF. It will alarm if the soldering iron temperature is higher or lower than the set alarm temperature. The upper and lower temperature range is ±20 to 80 °C

• Fault alarm function: Display S-E is a sensor fault; H-E is a heater core fault

Specification:

• Model: ST-965

• Power consumption: 65W

• Input voltage: AC 110V/220V

• Output voltage: AC 24V

• Display method: LED

• Temperature range: 200℃~450℃/392℉~842℉

• Temperature offset range: ±50℃ (±90℉)

• Temperature stability: ±1℃ at idle temperature

• Tip to ground resistance: <2Ω

• Tip to ground potential: <2mV

• Auto-sleep: 0~60 minutes (Default 10 minutes)

• Auto-turn off the heating: 0~60 minutes (Default 10 minutes)

• Dimensions: 210*88*150 mm

• Net weight: 1.97kg

Package includes:

• 1 x Soldering Station

• 1 x Soldering Iron Tip

• 1 x Soldering Iron Handle

• 1 x Soldering Iron Holder

• 1 x Ground Line

• 1 x Power Cable
