HYELEC MAS838 Multifunction Mini Digital Multimeter with Temperature Test Capability

Product Overview
The HYELEC MAS838 is a compact, hand‑held 3.5‑inch digital multimeter designed for stable, highly reliable and anti‑drop performance. It features a 15 mm high LCD display that provides clear readings. Powered by a LSI double‑integral A/D converter and protected by an overload circuit, this instrument delivers accurate measurements for a wide range of applications.

Key Features
• Compact and rugged hand‑held design
• 2000‑count LCD display for crystal‑clear readout
• LSI double‑integral A/D converter with overload protection
• Measures DC/AC voltage, DC current, resistance, diodes, temperature and continuity
• CE, CAT II 600 V, RoHS certified for safety

Specifications
DC Voltage: 200 mV / 2 V / 20 V / 200 V ± (0.5% + 2) / 600 V ± (0.8% + 2)
AC Voltage: 200 V / 600 V ± (1.2% + 10)
DC Current: 20 µA ± (1.0% + 2) / 200 µA / 2 mA / 20 mA ± (1.0% + 2) / 200 mA ± (1.5% + 2) / 10 A ± (3.0% + 2)
Resistance: 200 Ω / 2 kΩ / 20 kΩ / 200 kΩ ± (0.8% + 2) / 2 MΩ ± (1.0% + 2)
Display: 2000 Counts
Data Hold: ✔
Diode Test: ✔
Continuity Test: ✔
Temperature Measurement: ✔
Power Supply: 9 V 6F22 Battery
Safety Rating: CE CAT II 600 V RoHS
Package Size: 16 × 11 × 5 cm / 6.3 × 4.3 × 2.0 in
Package Weight: 310 g / 11 oz

Package List
1 × HYELEC MAS838 Digital Multimeter
1 × Test Cable
1 × Temperature Test Cable
1 × English Instructions
