PEAKMETER PM5910 Professional Digital RCD / Loop Tester – 0‑440 V AC Voltage, 500 mA Meter
0 out of 5 stars
No review yet| Qty | Price | Discount |
|---|---|---|
| 1 | NaN | |
| 3 | NaN | -3.2% |
| 5 | NaN | -4.8% |
| 10 | NaN | -7.2% |
Product details
Description
PEAKMETER PM5910 RCD/LOOP Tester Circuit Professional Digital 0-440V AC Voltage 500mA Meter
The PM5910 and MS5910 shown in the picture are shipped randomly, but they are actually the same product. We apologise for any inconvenience caused.
Key Features:
• Accurate tripping time and current measurements
• Tripping time: x1 IΔN 300 (slow 500 ms) ±3 ms 0.1 ms; x5 IΔN 40 ms (slow 150 ms) ±3 ms 0.1 ms
• Tripping current: (0.2‑1.1) IΔN ±0.1 IΔN 0.5 IΔN
• Contact voltage: 0‑99.9 V ±(10%+0.2 V) 0.01/0.1 V
• Alternating voltage (U I‑N, U L‑L, U L‑E): 0‑440 V ±(3%+3 V) 1 V
• Frequency: DC, 45‑65 Hz ±1 Hz 1 Hz
• Loop resistance (R L): 0.1‑2000 Ω ±(10%+0.2 Ω) 0.1 Ω
• R L current test: 0.51 IΔN ±(10%+10 % ) 0.5 IΔN
• Multiplying power of measuring current: ×0.5, ×1, ×5
• Current levels (IΔN): 10 mA, 30 mA, 100 mA, 300 mA, 500 mA
• Trigger phase angle: 0° or 180°
• Auto power‑off, back‑light display, low‑battery indication, USB 2.0 interface
• Data logging & recall: 100 groups
General Information:
Power supply: 6 × 1.5 V AA batteries (not included)
Category: CE ETL CAT III 300 V
Package size: 35 × 26 × 10 cm / 13.2 × 8.8 × 2.4 in
Package weight: 2020 g / 4.45 lb
Package List:
1 × RCD/LOOP Tester Circuit (battery not included)
1 × Portable bag
1 × Test probe
3 × Test clips
1 × English instructions
