LM2596 Non-isolated Constant Current Constant Voltage Module for Lithium-Ion Battery Charging

LM2596 Non-isolated Constant Current Constant Voltage Module for Lithium Ion Battery Charging

Features:

• The Fixed turn of the lamp current to 0.1 times the value of the constant current (At the when 2 identify been the is full)

• Increased input reverse polarity for protection, diode

• Using dedicated reference for IC, and high - precision from the resistor, so that the constant current is more stable (20 degrees to 100 degrees, the constant current 1A, when the temperature drift of less than 1%)

Specification:

• The Module Properties: Non-isolated constant current and voltage of the Module

• Rectification: Non-synchronous Rectification

• Input voltage: 7V-35V

• The output voltage: 1.25V-30V

• The Output current: Adjustable maximum 3A

• Conversion efficiency: 92% (Max)

• Switching frequency: 150KHz

• The output ripple: 50mV (Max) 20M bandwidth

• The Load Regulation: Plus or minus 0.5%

• Voltage Regulation: Plus or minus 2.5%

• Operating Temperature: - 40℃ to 85℃

Package includes:

• 1 x Module
