NASAN NA-LS2 Automatic LCD Laser Separation Machine for Battery Cover Separating Back Glass Refurbished

NASAN NA-LS2 Automatic LCD Laser Separation Machine for Battery Cover Separating Back Glass Refurbished

Features:

• For CellPhone Midframe/Bezel/Backglass Separating;

• Marking/Engraving（Wooden, Aluminum, Paint/Metal, Paper, Plastic, Leather）

• Intelligent Ranging System；

• Simple operation, easy to use；

• Support cloud download Software and drawings（Continuous updating...)

• No built-in computer, need to use it with Windows 7/8 system computer together.

• Laser Watt: 4.5W

• Position: Manually

• Pulse Width(ns): ~5ns

• Peak Power(kW): ~36kW

• Repetition Rate(kHz): ~25kHZ

• Transverse Mode: TEMoo

• Full Angle Divergence: ＜1.5

• Wave Length: 1.06μm

• Marking Depth: 0.015-0.5mm

• Max Marking size: 175*175mm

• Light Spot: Φ0.05-0.01mm

• Precision: ≤0.001mm

• Repeat Marking Precision: ≤0.001mm

• Marking Speed: ≤10000mm/s

Package includes:
1 x Laser Separating machine
