Portable Powerful Metal DS Logic Logic Analyzer 16 Channels Sampling USB-based Debugging Logic Analyzer

Portable Powerful Metal DS Logic Logic Analyzer 16 Channels Sampling USB-based Debugging Logic Analyzer

Features:

• DSLogic is a USB based logic analyzer.

• It can provide up to 400 MHZ real-time samplings, the status of 50 MHZ sampling, sampling depth of 16 M * 16 channel.

• The realization of high-voltage electrostatic TVS and ESD protect, also supports continuous voltage input protect and USB interface flow protection.

• Two modes, stream mode through USB real-time transmission, using PC memory to store data, buffer mode with hardware memory achieve a high sampling rate.

• Support adjustable threshold, compatible with various voltage standard, turn off the interference area automatically.

• A metal surface, 360-degree noise shielding can meet the complex surrounding test needs. Quick heat elimination, stable electric heating working.

• It has a 1.6 Gbps sampling bandwidth.

• Covering almost all common serial board-level and field level bus protocol, with clear and intuitive data and convenient to see.

• Small size, easy to carry, use USB power, easy on-site commissioning.

Specifications:

• Material: plastics

• Type: Basic version, Upgrade version (optional)

• Model Number: DSLogic Logic Analyzer

• Model: stream+buffer

• Maximum sampling rate:

• 4 channels @ 400 MHZ

• 8 channels @ 200 MHZ

• 16 channels @ 100 MHZ

• Continuous Adjustable Threshold Voltage Range: 0.5 V to + 5 V

• The Input Voltage Range: - 30 V to + 30 V

• Input Impedance: 250 kohm

Basic Version:

• The onboard storage depth: Total 64M

• Hardware Memory: 64M

• The Largest State Sampling Clock: 30 M

Upgrade Version:

• The onboard storage depth: Total 256 M

• Hardware Memory: 256Mbits

• The Largest State Sampling Clock: 50 M

Package includes:
Basic Version:
1 x Basic Main Machine
1 x Type-C Data Cable
4 x DuPont Line
16 x Clip

Upgrade Version:
1 x Plus Main Machine
1 x Type-C Data Cable
5 x Shield Line
16 x Clip
