Pro'sKit SS-331H ESD LCD Digital Electric Desoldering Pump with Suction Vacuum Solder Sucker - 220V

Pro'sKit SS-331H ESD LCD Digital Electric Desoldering Pump with Suction Vacuum Solder Sucker

Features:

• The electric type allows you to save time and worry. Intelligent control + strong suction + high efficiency

• Suitable for large-scale disassembly of integrated circuit boards in factory assembly lines, repair shops, etc., to improve work efficiency

• Precision design, automatic control, precise temperature control of 160-480℃

• Using high-efficiency ceramic, heating up quickly

• The LCD screen can quickly set the temperature and easily control the status

• Transparent solder bath, tin dross can be seen and cleaned more easily

• Stainless steel through needles This machine is equipped with 3 kinds of diameter stainless steel through needles, select the suitable through the needle to clean the nozzle hole

Specification:

• Model: SS-331H

• Voltage: AC 240V

• Power: 90W

• Power Consumption: 140W

• Temperature: 160℃--480℃

• Control System: Microprocessor

• Vacuum Pump System: Air Pump Motor

• Vacuum Suction: >600mm Hg

• Insulation Resistance:100MΩ

• Ground Resistance:0.3Ω

• Heating Principle: Ceramic Heating

• Tube Length:105cm

• Power Cable Length: 1.2M (3 core cord ground plug)

• Size: 172*135*190MM

Package includes:

• 1 x Pro'sKit SS-331H
• 1 x Power Cable
• 3 x Nozzles

Notes:

• After Each Use. It is recommended to take 3-5 times Empty Suction to Full Clear the residual Tin in The Tube

• If the interval is about 20 minutes, it is recommended to use a needle to clean the steel pipe after emptying the suction

• During the use, If the suction is reduced. Please use a needle to clean the steel pipe

• If you do not use it often, it is recommended to adjust the tin gun to about 200 degrees, and then adjust to the working temperature when using it

• When there is about 1/2 of the tin slag in tin storage. It should be cleaned in time. When the filter Spong is hard, Pls replace it in time
