Refox RK10 5W Cold Light UV Laser Machine for Mobile Phone Frame / Back Glass / Bracket Disassembly

Refox RK10 5W Cold Light UV Laser Machine for Mobile Phone Frame / Back Glass / Bracket Disassembly

Features:

• REFOX RK10 is a next-generation cold light UV laser marking machine designed for professional mobile phone repairs and precision marking.

• Leveraging a UV cold light source enables safe and accurate adhesive softening for front glass OCA, back covers, and screen brackets, without the risk of burning or damaging sensitive components

• Equipped with a built-in operating system and an extensive model library with OTA updates, the RK10 provides up-to-date templates for hundreds of devices

• The Smarter Way to Separate Front Glass: Glass separation in 2 mins, no more cutting wire

• Beyond phone repair, the RK10 supports laser marking on diverse materials such as plastics, metals, wood, and leather, unlocking expanded business opportunities

Specification:

• Model: RK10

• Voltage: 110V/220V

• Power: ≤500W

• Laser Power: 5W

• Working Area: 180*180mm

• Screen Size: 215*135mm

• Marking Line Width: 0.05~0.1mm

• Wavelength: 355nm

• Cooling Method: Air-cooled

• Lifespan: >10000H

• Marking Depth: 0.015~0.5mm

• Marking Precision: 0.01mm

• Marking Speed: ≤10000mm/s

• File Formats: JPG/JPEG/BMP/PNG/PLT/DXF

• Spot Shape: Round

• Max.Marking Height: 65mm

• Product Size: 406*304*543mm

• Net Weight: 27kg

Package includes:

• 1 x UV Laser Machine

• 1 x Power Cable
