STM32-QFP100 Mass Production Programming Seat Test Socket Download Tool

STM32-QFP100 Mass Production Programming Seat Test Socket Download Tool

Features:

• Use: Test and program STM32-QFP100 packaged chips.

• Applicable models: STM32L1xxV series (such as: STM32L151VB, STM32L152VB); STM32F1xxV series (such as: STM32F103VE, STM32F100VE); STM32F2xxV series (such as: STM32F207VC, STM32F215VC); STM32F3xxV series (e.g. STM32F303VC, STM32F373VB); STM32F4xxV series (e.g. STM32F407VG, STM32F415VG)

• Pin out all the pins of the chip in rows of pins with a pin pitch of 2.54mm (100mil)

• On-board JTAG, SWD, UART1 interfaces, can be directly related to the model for testing, writing

• On-board high-speed external crystal socket (crystal can be customized)

• On-board two LEDs, can be used for test status indication (jumpers can be skipped, does not take up I / O resources)

STM32-QFP100 Test Sockets Detailed specifications of the applicable chips and the external dimensions of the adapter:

• Model: LQFP-100-0.5-01

• Pin distance: 0.5

• Pin position: 100

• Long* type (body): 14×14

• Long * type (including pins): 16×16

Package includes:

• 1 x Test Socket
