UNI-T UT171A Industrial True RMS Digital Multimeter with USB Interface & LCD Backlight

UNI-T UT171A Industrial True RMS Digital Multimeter with USB Interface & LCD Backlight

Features:

• Measuring speed (5 times/s) is two times the speed of the other ten thousand meters

• Variable square wave signal output (frequency 0~4800Hz 0.5Hz, low impedance)

• Counts 40000/60000 RMS True

• LoZ AC voltage test

• uA/mA/A AC/DC current test

• AC+DC measurement model

• Resistance, electrical conductivity measurement nS

• VFC household industrial frequency conversion voltage test

• Built-in lithium battery 7.4V/1800mA,charging tips circuit

• Temperature test -40℃ ~1000℃

• III 1000V/CAT IV600V CAT

• With electronic storage records 1000/10000

• Support USB/Bluetooth transmission mode

• Anti misplugging alarm

• It can be used for large current 20A measurement

• Safety certification: CE, cETLus

Specification:

• Model: UT171A

• DC Voltage: 400mVI4V/40V400V/1000V ±(0.025%+5)

• AC Voltage: 400mV14V140V400V750V ±(0.4%+40)

• DC Current: 400uA/4000uA/40mA/400mA/4A/10A ±(0.15%+2)

• AC Current: 400uA/4000uA/40mAJ400mA/4A/10A ±(0.75%+5)

• Resistance: 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ ±(0.05%+2)

• Capacitance: 4nF140nF/400nF/4μFI40uF/400uF/4mF/40mF ±(2.5%+40)

• Frequence: 10Hz~10MHz ±(0.01%+5)

• Display Count: 40000

• Auto/Manual Range: Yes

• True RMS: Yes

• Bandwidth(Hz): Yes

• Diode: Yes

• Continuity Buzzer: Yes

• Duty Cycle: Yes

• NCV: Yes

• Data Hold/MAX/MIN: Yes

• Relative Mode: Yes

• Data Storage: 999

• USB Interface: Yes

• Display Type: LCD

• CD Backlight: Yes

• Analogue Bar Graph: Yes

• Mis-plug Alarm: Yes

• Low Battery Indication: Yes

• Auto Power Off: Around 15 Minutes

• Input Protection: Yes

• Input Impedance for DCV: Around 1GΩ

• Power: AA 1.5V Battery x 6 (Not includes)

• Product Color: Red and Grey

• Product Net Weight: 384g

• Product Size: 206*95*55mm

Package includes:

• 1 x Multimeter (without Battery)

• 1 x Test Lead

• 1 x Point Contact Temperature Probe

• 1 x USB Interface Cable
