UNI-T UT682 RJ11 RJ45 Wire Tracker Line Finder Telephone Wire tracker Network Cable Tracer Tester

UNI-T UT682 - Wire Tracker consists of a transmitter and a receiver. It has functions like telephone wire tracking, network wire tracking, cable wire tracking, network wire check, etc. and it has fast and accurate measurements. UT682 is an ideal tool for personnel to install and maintain network systems with communication lines and integrated wiring circuits.

Features:

• Product name: Wire Tracker
• Power supply: 9V Battery (NOT included)
• Signal transmission form: Multifrequency pulse
• Short circuit, open circuit test: Support
• Telephone line polarity instructions: Support
• Audio signal test range: ≥1000m
• Video line distance: ≥100m
• Low battery indication(Transmitter): Support

Telephone Line Tracking Function

• Connect the telephone line head into the transmitter’s RJ11 interface;
• Press the transmitter functional select switch to the “TEST” position. Line tracking indicator “Status” will flask, which indicates that the transmitter works properly;
• Hold down the receiver “Press to test” button and look for the target cable with the receiver probe.
• During the testing, light press the “Switch” button to switch between single and double audio test patterns.

• The network line with a crystal head into the transmitter RJ45 interface;
• Press the transmitter functional select switch to the “TEST” position, Line tracking indicator “Status” will flash, which indicates that the transmitter works properly;
• Hold down the receiver “Press to test” button and look for the target cable with the receiver probe.
• During the testing, light press the “Switch” button to switch between single and double audio test patterns.

• Connecting the transmitter with the metal cable using alligator clip adapter wiring;
• Adjust the transmitter functional select switch to the “TEST” position, line tracking indicator “Status” will flash, which indicates that the transmitter works properly;
• Hold down the receiver “Press to test” button and look for the target cable with the receiver probe.
• During the testing, light press the “Switch” button to switch between single and double audio test patterns.
