UNI-T UT71C True RMS Intelligent Digital Multimeter with USB Data Transfer

UNI-T UT71C True RMS Intelligent Digital Multimeter with USB Data Transfer

Features:

• UT71C 39999 count is 4 3/4 Auto range True RMS digital multimeter with analog bar graph display full-featured, full-range overload protection

• Suitable for metallurgy, electronics, telecommunications, manufacturing, petroleum, defense, power, chemical and other industries and major colleges

• Also used to solve electronics, factory automation, power distribution, and electromechanical equipment problems

Specification:

• Model: UT71C

• DC Voltage: 400mV4V140V/400V/1000V ±(0.025%+5)

• AC Voltage: 4V/40V/400V/1000V ±(0.4%+30)

• DC Current: 400uA/4000uA/40mAV400mA/10A ±(0.1%+15)

• AC Current: 400uA/4000uA/40mA/400mA/10A ±(0.7%+15)

• Resistance:  400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ ±(0.3%+8)

• Capacitance: 40nF/400nF/4uF/40uF/400uF/4mF/40mF ±(1%+20)

• Frequency: 40Hz~400MHz ±(0.01%+8)

• Temperature: -40℃~1000℃ ±(1%+30)

• Temperature: 40℉~1832℉ ±(1.5%+50)

• Display Count: 39999

• Auto Range: Yes

• True RMS: Yes

• Bandwidth: 100KHz

• Duty Cycle: 10%~90% ±(1%+30)

• Diode: Yes

• Auto Power Off: Yes

• Continuity Buzzer: Yes

• Low Battery Indication: Yes

• Data Hold: Yes

• Relative Mode: Yes

• MAX/MIN: Yes

• Data Logging: 100

• JSB Interface: Yes

• Double Backlight: Yes

• Analogue Bar Graph: Yes

• Full Icon Display: Yes

• Setup: Yes

• Input Impedance for DCV: DC 400mV: Around 2.5GQ, All Other Range 10MΩ

• 4-20mA Loop: 0-100%

• Current Measurement Alarm: Yes

• Voltage Current AC+DC Measurement: Yes

• Power: 9V Battery 6F22 (Not includes)

• Product Color: Red and Grey

• Product Net Weight: 384g

• Product Size: 200*93*40 mm

Package includes:

• 1 x Multimeter (without Battery)

• 1 x Test Lead

• 1 x Point Contact Temperature Probe

• 1 x USB Interface Cable
