Yamaha Immobilizer Emulator for Yamaha Bikes

Yamaha Immobilizer Emulator for Yamaha Bikes

Features:

• Immobilizer Emulator for Yamaha motorcycles and scooters

• Works with all motorcycles and scooters Yamaha from 2006 to 2009

• Does not demand to program only need is connect wires

• Completely emulates the work of a regular immobilizer, including light-emitting diode work on the instrument panel

For emulator installation in the case of a regular immobilizer:

• Remove glue hermetic from the immobilizer case

• Take out a PCB from the immobilizer and desolder from its wires

• Connect the emulator according to drawing more low

• Insert the emulator into the immobilizer case

Colouring of wires and their appointment:

• Black (2 pcs.)  GND

• Red  BATT (+12v)

• Yellow IGN (+12v)

• Gray  LED (+5v)

• Blue K-line Immo-ECU

Package includes:

• 1 x Immobilizer Emulator
