Z3X Easy Jtag Plus Box - Full Version + EMMC Socket + NAND Socket

$275.00
In stock
SKU
MV103968
  • Buy 3 for $270.00 each and save 2%
  • Buy 5 for $265.00 each and save 4%
  • Buy 10 for $260.00 each and save 6%

Z3x Easy Jtag Plus Box - Full Version With eMMC Socket, which boasts some MAJOR hardware improvements and Features including One click device repair, Boot repair, Data recovery, eMMC firmware repair, Partition management, eMMC service operations, SPI memory programming.

This Upgraded PLUS version features ultra fast data transfer, has the possibility of increasing functionality in the future: hardware of the new box is ready to support new protocols like UFS* and NAND*.

Box Features

  • One click device repair
  • Boot repair
  • Data recovery
  • eMMC firmware repair
  • Partition management
  • eMMC service operations
  • SPI memory programming


Socket Features

  • Combining the top quality materials with best engineering and elegantly designed hardware for the powerful eMMC Socket.
  • Made from the high quality materials
  • Over 10K cycles of lifetime performance in your service center
  • Wide range of eMMC IC supported by: BGA153/169, BGA162/186, BGA221, BGA529
  • High-speed up to 30 MB per second over 8 bit bus.
  • EMI resistant design, low noise components
  • Integrated power logic. Additional power source is no more need
  • Surge protection - smart fuse driven (0.5A threshold)


Software Features

  • DUMP AND PINOUTS DATABASE

Free access to large dump and pinouts database and constantly updated software tools

  • EASY JTAG TOOL

The main application allowing you to use most of the product features. It's the most powerful tool of all

  • EASY JTAG PLUS TOOL

Lightweight software, made especially for mobile phones repair, eMMC memory chips replacement and user data recovery

  • EASY JTAG SPI FLASHER

Identifying, reading, writing, verifying and erasing flash chips. It is designed to flash BIOS images on mainboards, routers, e.t.c.

  • EASY JTAG SINGLE PACKAGE REPAIR

Create user customized repair packages. This is partition layout, pinout, eMMC preconfig and instructions

  • EASY JTAG API

Access to most useful box functionality to create your own decisions


Main benefits of new Z3x Easy Jtag Plus Box

  • Updated CPU AT SAM3X8E vs LPC1768 in old box.
  • Updated FPGA SPARTAN6 vs SPARTAN3 in old box
  • Updated Power Logic – Full Digital PWM with ADC control.
  • MicroUSB Connector if additional power required.
  • VCC and VCCQ overload protection.
  • Updated host interface: USB 2.0 Device/Mini Host: 480 Mbps
  • Integrated ISP engine: Z3X High Power Pro Engine
  • ISP Support 1 and 4 bit connection now **
  • Added eMMC 8 bit high speed interface up to 48Mhz
  • Integrated NAND engine: NFC with 4 Kbyte RAM buffer and ECC
  • Integrated M-PHY interface.
  • Integrated SPI/I2C engine: up to 65 MHz for HSMCI and SPI clock lines
  • Integrated Self Test Core that exclude 90% faults in production.
  • Integrated CCID Card Reader for Z3X Software Use


What you get with new hardware :

  • Box to Host PC speed increase up to 35MB/sec
  • JTAG Interface speed increase 20%
  • eMMC ISP Speed increase up to 4MB/sec
  • eMMC 8 Bit Speed up to 26MB/sec
  • Compatibility with 99.9 host PC systems and OSes
  • Compatibility with old Easy JTAG G1 ISP adapters ( 1bit )
  • Adapter-less ISP ( all stuff inside the box )
  • Compatibility with all market popular eMMC sockets ( 8 bit )
  • True Plug and Play for modern Windows OS ( 8, 8.1 , 10 )
  • Full Support for legacy OS like Windows XP

The main features of a new hardware are:
- Updated Host MCU SAM3X8E vs LPC1768 in old box.
- Updated HIGH SPEED FPGA SPARTAN6 vs SPARTAN3 in old box
- Updated POWER MANAGEMENT subsystem – Full Digital PWM with ADC control.
- Added microUSB Connector if additional power required.
- Added VCC and VCCQ switch with overcurrent protection.
- Updated USB device interface: USB 2.0 480 Mbps (High Speed)
- Integrated ISP engine: Z3X High Power Pro Engine (4Mb/s )
- ISP Support 1 and 4 bit* connection now.
- Added eMMC 8 bit high speed interface up to 42Mhz
- Integrated NAND* engine: NFC with 4 Kbyte RAM buffer and ECC
- Integrated M-PHY* interface.
- Integrated SPI engine: up to 21 MHz clock for popular SPI Memory Flash IC
- Integrated Self Test Core that exclude 90% faults in production.
- Integrated CCID Card Reader for Z3X Software Use

The main benefits of a new hardware are:
- Box to Host PC speed increased up to 40MB/sec
- JTAG Interface speed increased 20%
- eMMC 1 Bit ISP Speed increased up to 4MB/sec
- eMMC 4 Bit ISP Speed increased up to 12MB/sec (eMMC 5.0+) **
- eMMC 4 Bit Speed up to 18MB/sec
- eMMC 8 Bit Speed up to 28MB/sec ( eMMC 5.0+ )
- Compatibility with 99 host PC systems and OS’s
- Compatibility with old Easy JTAG gen. 1 ISP adapters (1bit)
- Adapter-less ISP (all stuff inside the box)
- Compatibility with all market popular eMMC sockets (with supplied adapters)
- True Plug and Play for modern Windows OS (8, 8.1, 10)
- Full Support for legacy OS like Windows XP

eMMC socket is:
- Made from the high quality materials
- Have 10000 cycle of lifetime performance in your service center
- Wide range of eMMC IC supported by: BGA153/169, BGA162/186, BGA221, BGA529
- High-speed up to 40 MB per second over 8 bit bus.
- EMI Resistant Design, Low Noise Components.
- Integrated power logic! No need of the additional power!
- Surge Protection - smart fuse driven (0.5A threshold).
- Easy to operate, just turn and click.
- Like any other Z3X crafted thing - the best solution at the market ;-)

Easy NAND socket for Easy-Jtag Plus
Support Iphone 4 4s 5 5s 6,IPAD,read write Boot,WIFI SN....

Package include:
1 x Easy JTAG Plus Box Main Interface Hardware
1 x Z3X Certified EMMC Socket (BGA153/169, BGA162/186, BGA221, BGA529)
1xJTAG Pin 20 Standard Cable.
1xISP Soldering connector 1bit.
1xISP Soldering connector 4bit.
1x20P to 20P Adapter for E type Socket.
1x20P to 20P Adapter for U type Socket.
1 x USB A to B Cable
1 x NAND Socket Set
