UM34 UM34C Type-C 1.44inch Color LCD Portable USB Current Voltage Detector

UM34 UM34C Type-C Color LCD Meter Portable Digital USB Multimeter, Mobile phone Power Voltage Current Multimeter USB Charger Detector, Digital Multi-function USB Charger / USB Out Voltage Current Capacity Multimeter Detector. The working time and Capacity have Memory function when power off

• Product Model: UM34 / UM34C

• Display screen: 1.44 Inch color LCD screen

• Voltage measuring range: 4-24.000 V

• Voltage measurement resolution: 0.01 V

• Current measuring range: 0-5.0000A

• Current measurement resolution: 0.001A

• Capacity accumulation range: 0-99999 mAh

• Voltage measurement accuracy:±(0.2％+1digit)

• Energy accumulation range: 0-999.99Wh

• Current measurement accuracy:±(0.8％+3digits)

• Impedance range: 0.8 Ω-9999.9 Ω

• Time measurement range:0-99h59min59s

• Temperature measurement error:±3℃/±6℉

• Screen brightness setting: 0-5 levels

• Auto screen off time: 0-9 mins

• Voltage graphs range: 0-24.00 V

• Current graphs range: -4,000A

• Refresh rate: 2Hz

• Quick charge recognition mode:QC2.0、QC3.0、APPLE 2.4A/2.1A/ 1A/0.5A、Android DCP、SAMSUNG


Notes:

1. UM34 without Bluetooth connection, UM34C with Bluetooth connection. And UM34C do not have PC software, only have APP for android.

2. Phone Android (Android 5.0 and above, support 18 kinds of language, Chinese, English, Russia and etc)

3. There is some incompatibility problem between some android phones and our Bluetooth boards.  Please purchase carefully, such as Samsung NOTE8 / S8

   For Android APP:


            allow APP only support android 5.0 and above.
            allow APP to be done in the background, not be cleaned.
            allow APP self-starting point.
            allow APP to remain locked after screen, not be cleaned.
            Type-C is just measuring, not all Type-c quick charge, not trigger

Packing includes:
1 x USB Multimeter
